Select from ACO’s Complete the Look gratings and combine with an ACO channel to deliver both an aesthetic surface finish and effective drainage for your paved surfaces. Select a grate to complement your aesthetic: Make your ACO channel drainage disappear, stand out or blend in against your paving.
All gratings are compatible with ACO’s HexDrain® and RainDrain® channels, which deliver effective surface drainage for most domestic installations.* Carrying the load: Each grating is tested to withstand either pedestrian (A 15 load class) or vehicle traffic (B 125 load class). *A 10m run of HexDrain or RainDrain could drain up to 145m² paved area during a 50mm per hour rainfall event (in accordance with the guidance in Building Regulations for England 2015 Section H3 2.4).
Benefits
- Galvanised completes the look of driveways and patios
- Designed to be used with ACO's best-selling domestic drainage channels ACO HexDrain and ACO RainDrain
- Suitable for patios and garage thresholds
- Each grating is tested to withstand either pedestrian (A15) or vehicle Traffic (B125)
| Product Brand | Aco |
|---|---|
| Material | Steel |
| Finish | Zinc Coated |
| Load Capacity | 1.5 tonnes |
| Weight (kg) | 1.3 |
| Thickness Metric (mm) | 15 |
| Length | 1000mm |
| Height | 19.3 mm |
| Width | 118mm |
| Manufacturer Code | 3003858 |
